Product size
This page shows the product size of the NL-EB15 safety device. The dimensions depend on the cover version.
Metal cover version
The drawing below shows the dimensions of the metal cover version.
Plastic cover version
The drawing below shows the dimensions of the plastic cover version.
Notes
- The overall dimensions are shown for both cover versions. - Verify the mounting clearance and the cable routing before installation. - The dimensions are nominal; refer to the installation picture page for the mounting accessories.
